SILVAN 500L LINKAGE CANNON JET SPRAYER - MIN 75HP

Linkage air assist Cannon Jet 500 litre sprayer with a 88 L/min diaphragm pump, Cannon Jet single-sided conveyor with hydraulic tilt adjustment, and electric valve controls.

Specifications:

Market: Horticulture
Tank Size (L): 500
Connection Type: Linkage
Min HP: 75
Pump Size (L/min): 88
Height / Width / Length (mm): 2500 / 1190 / 1400
Product Weight (kg): 140 (dry)
Application: Strawberries, flowers, greenhouse, vegetables, parks & gardens

Features:

Pump: Silvan oil-backed diaphragm type with nitrile diaphragms, corrosion resistant, cast anodised aluminium body. APS96: 88L/min capacity, 5000kPa pressure.

Fan Size: 450mm diameter twin turbine fan with galvanised frame and spray head. Hydraulic angle adjustment and manual top wing adjustment

Nozzles: Flip-over type with ceramic hollow cone nozzles. 9 nozzles (6 in cannon head, 3 inside of cannon) with twist on/off.

Gearbox: Two speed with neutral position, oil bath type.

Controls: 40bar electric section valves, master valve, electric pressure regulator and in cab controls.

Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, non spill lid. 40 litre fresh water tank fitted to 2000L unit.

Frame: 500L: Galvanised steel, suit cat I & II linkage. 2,000L: Galvanised steel with jockey wheel and adjustable drawbar.

Agitation: 500L: dual bypass. 2,000L: pump bypass plus venturi agitator.

Pressure Gauge: 100mm, 0-60 bar glycerine filled gauge with bar increments.

Filtration: Lid strainer, suction line strainer and stainless steel nozzle filters.

PTO Driveshaft: Quality driveshaft with quick release pins and safety cover. Constant velocity shaft.

HP Required: Minimum 75hp.

Options:

- Bravo 180s automatic rate controller (D99-143)
